Item # |
Inlet and Discharge Size |
Recommended Floor Space |
Nominal Drain Size |
Drain Type |
|---|---|---|---|---|
| VIS-4 | Inlet and Discharge Size N/A 4 in | Recommended Floor Space N/A 2 ft² | Nominal Drain Size N/A 2 in | Drain Type N/A Flange (FLG) |
| VIS-5 | Inlet and Discharge Size N/A 5 in | Recommended Floor Space N/A 3-1/2 ft² | Nominal Drain Size N/A 2-1/2 in | Drain Type N/A Flange (FLG) |
| VIS-6 | Inlet and Discharge Size N/A 6 in | Recommended Floor Space N/A 4 ft² | Nominal Drain Size N/A 3 in | Drain Type N/A Flange (FLG) |
| VIS-8 | Inlet and Discharge Size N/A 8 in | Recommended Floor Space N/A 6-1/2 ft² | Nominal Drain Size N/A 4 in | Drain Type N/A Flange (FLG) |
| VIS-10 | Inlet and Discharge Size N/A 10 in | Recommended Floor Space N/A 7 ft² | Nominal Drain Size N/A 4 in | Drain Type N/A Flange (FLG) |
| VIS-12 | Inlet and Discharge Size N/A 12 in | Recommended Floor Space N/A 12 ft² | Nominal Drain Size N/A 5 in | Drain Type N/A Flange (FLG) |
| VIS-14 | Inlet and Discharge Size N/A 14 in | Recommended Floor Space N/A 16 ft² | Nominal Drain Size N/A 6 in | Drain Type N/A Flange (FLG) |
| VIS-16 | Inlet and Discharge Size N/A 16 in | Recommended Floor Space N/A 21 ft² | Nominal Drain Size N/A 6 in | Drain Type N/A Flange (FLG) |
| VIS-18 | Inlet and Discharge Size N/A 18 in | Recommended Floor Space N/A 22 ft² | Nominal Drain Size N/A 8 in | Drain Type N/A Flange (FLG) |
| VIS-20 | Inlet and Discharge Size N/A 20 in | Recommended Floor Space N/A 28 ft² | Nominal Drain Size N/A 8 in | Drain Type N/A Flange (FLG) |
| VIS-22 | Inlet and Discharge Size N/A 22 in | Recommended Floor Space N/A 34 ft² | Nominal Drain Size N/A 10 in | Drain Type N/A Flange (FLG) |
| VIS-24 | Inlet and Discharge Size N/A 24 in | Recommended Floor Space N/A 39 ft² | Nominal Drain Size N/A 10 in | Drain Type N/A Flange (FLG) |
| 1382 | Inlet and Discharge Size N/A | Recommended Floor Space N/A | Nominal Drain Size N/A | Drain Type N/A |
